Stainless Steel Hose Clamps
Quick Realease Hose Clamps
Quick Realease Hose Clamps
Quick Realease Hose Clamps
Quick Realease Hose Clamps
Quick Realease Hose Clamps

Quick Realease Hose Clamps

Tool-free Operation, Ideal for Frequent Hose Changes
12.7 & 14.2mm Wide, Made of SS201 & 304
Min. Order: 1,000 PCS
Reference FOB Price: 0.5~2.0 USD/PCS
Basic Info & Terms

Place of Origin:  China

Brand Name:  LONYOU

Payment Terms: T/T, L/C

Certification:   CE RoHS

Supply Ability: 100,000 PCS/Month

Description

Reviews

Quick Release Hose Clamps are designed for applications requiring fast and frequent connection and disconnection of hoses, pipes, or tubes. Featuring a convenient lever or cam-operated mechanism, these clamps allow for rapid opening and closing without the need for tools. This makes them ideal for situations where maintenance, cleaning, or equipment changes are common, providing a secure and leak-proof seal while significantly reducing downtime.

Features

  • Enables rapid connection and disconnection of hoses without tools.
  • Features a user-friendly lever or cam-locking mechanism.
  • Provides a secure and leak-proof seal when closed.
  • Constructed from durable materials such as stainless steel or zinc-plated steel for corrosion resistance.
  • Available in various sizes to accommodate different hose diameters.
  • Offers adjustable clamping force to suit different hose materials and pressures.
  • Simplifies maintenance, cleaning, and equipment changes.
  • Reduces downtime associated with hose connection and disconnection.
  • Suitable for a wide range of applications in industries such as food and beverage, pharmaceutical, chemical processing, and irrigation.
  • Some designs may include safety locking features to prevent accidental opening.

Technical Data

  • Material Options: Stainless Steel 201 & 304
  • Size Range (Hose OD): Typically from 1/2" (12.7mm) up to 6" (152.4mm) or larger, depending on the model
  • Maximum Operating Pressure: Varies significantly based on size, material, and design (e.g., from 50 PSI to several hundred PSI). Refer to specific product specifications.
  • Operating Temperature Range: Dependent on the material and seal used (e.g., -20°C to +100°C for standard materials, wider ranges available with specific materials).
  • Locking Mechanism Type: Lever Cam, Over-Center Latch, Spring-Loaded
  • Band Width: Varies depending on the size and pressure rating of the clamp
  • Corrosion Resistance: Stainless Steel Offers excellent corrosion resistance (grade dependent).
  • Installation: Designed for manual operation, no specialized tools required for opening and closing.
  • Applications: Food processing, beverage production, chemical transfer, irrigation systems, quick connect couplings, filter housings, pump connections.

Specifications

Code Diameter
(mm)
Width
(mm)
Thickness
(mm)
Material
QRH010 13-32 12.7/14.2 0.7 W2/W4
QRH020 19-44 12.7/14.2 0.7 W2/W4
QRH030 26-51 12.7/14.2 0.7 W2/W4
QRH040 26-57 12.7/14.2 0.7 W2/W4
QRH050 26-70 12.7/14.2 0.7 W2/W4
QRH060 38-89 12.7/14.2 0.7 W2/W4
QRH070 26-101 12.7/14.2 0.7 W2/W4
QRH080 51-127 12.7/14.2 0.7 W2/W4
QRH090 51-152 12.7/14.2 0.7 W2/W4
QRH100 45-178 12.7/14.2 0.7 W2/W4
QRH110 45-197 12.7/14.2 0.7 W2/W4
QRH120 55--216 12.7/14.2 0.7 W2/W4
QRH130 45-228 12.7/14.2 0.7 W2/W4
QRH140 51-254 12.7/14.2 0.7 W2/W4
QRH150 51-311 12.7/14.2 0.7 W2/W4

To customize any other sizes, please contact sales for further information.
